ScoutWatch
Instructions
When you power ON the ScoutWatch it will go to
the same location (mode) that you last used. Previous data and settings will be retained. After power ON, all displayable
segments will show for 1 second, after which the current mode is displayed on the left side of the display.
MPH The
MPH mode allows you to measure pitch speed in MPH. Simply press down
the "START" button on the pitcher’s
release and let up when the ball is caught.
The pitch speed will display in MPH. If the ball is hit, press and release
"START"
when the batter reaches 1st base and read both the PITCH SPEED and runner’s
time-down-the
line, alternating every second. Press RESET to advance to the
next pitch. The next pitch count will be displayed.
KPH
The KPH mode works in the same way as MPH, except the results are expressed
as KPH instead of MPH. To change the mound
distance, press RESET twice,
then use the START button to select the distance, 60, 46, 55, 54, 50, 43, 40, or
35
feet, followed by RESET. Te next pitch count will be displayed.
PCH In the PCH (Pitch Count/HOME) mode, the Strikes
and Balls will be counted
using the "BALL" and "STRIKE" buttons. The balls and strikes are separated
by
a colon, and alternate with the TOTAL pitches thrown.
PCA In the PCA (Pitch Count/AWAY) mode, ball and strikes
will be kept for the
"AWAY" pitcher. Either PCH or PCA can be reset to 00:00 by pressing
"RESET"
for 5 seconds. The other pitch count will not be effected. Typing
"MODE" will revert back to the "HOME"
pitcher’s statistics.
UMP To exit PCH or PCA, hold the mode button down for 2 seconds, and the
ScoutWatch
will advance to the "UMP" umpire mode. Using the "BALL" and
"STRIKE" buttons, the ScoutWatch
acts as a "clicker", but will automatically
advance OUTS, and reset the count to 00:00. If an out occurs in
the field simply
press the STRIKE button until an OUT is registered.. After 3 outs, the display
resets to 00:00
for the next ½ inning.
TIM The TIM (timer) mode allows you to use the ScoutWatch exactly as a stopwatch.
TIM/MPH
The TIM plus MPH mode enables you to set any distance (default is 5280 ft, 1
mile), and calculate the MPH for a vehicle
traveling that distance, around a
racetrack, for instance. Simply press and release the START button at the
beginning
of the lap and at the end of the lap and read the speed in MPH along
with the elapsed time. Reset using the RESET button.
To change the distance,
press the RESET button to display the current distance (in units of 10 feet). Then
using
the START and MODE buttons, increase or decrease the distance. By
incrementing in units of 10 feet, a distance of 99990
feet can be programmed,
almost 19 miles. To set 1 mile, 528 should be displayed. For metric distances,
convert
to feet, ie, 10K = 32,808 ft., so set 3281 in the program mode. After the
distance is displayed, push the RESET button.
It will remain in memory even
if the ScoutWatch is turned OFF. Maximum measurable speed is 999 MPH.
At any
time, pressing the MODE button for 3 seconds will power down WITHOUT losing any previous data.
If you have any questions,
please call Sports Products Consultants at 800/474-8243. The ScoutWatch uses a 3 volt 2L76-type battery, accessible
thru the coin-operated door on the back cover. To eject the battery, use a coin to open the battery door and tap the ScoutWatch
against your palm. Insert a new battery, negative (-) side down. Replace the door securely. Check for the watertight O-ring
beneath the door.
ScoutWatch is a Registered Trademark of Sports Products Consultants. ScoutWatch is patented in the
USA. Software is protected by US Copyright.
